Industrial IoT Platform Architecture
Discover how our comprehensive platform connects your factory floor to the cloud, delivering actionable insights through a secure, scalable architecture.
Platform Components
Our comprehensive IoT ecosystem consists of integrated hardware and software components that work together seamlessly.
Hardware Devices
Our industrial-grade hardware connects to your existing equipment and sends data securely to the cloud.
Edge Software
Our edge software runs on our hardware devices, processing data locally before transmitting to the cloud.
Cloud Platform
Our cloud platform stores, processes, and analyzes data from all connected devices in your factory.
User Applications
Access your data and control your devices through our intuitive web and mobile applications.
Data Flow Architecture
Understand how data moves through our platform from your factory equipment to actionable insights.
Data Flow Visualization
Data Collection
Sensors and equipment generate raw data
Edge Processing
Local filtering and pre-processing
Cloud Transmission
Secure data transfer to cloud
User Visualization
Dashboards and mobile apps
Data Analytics
ML algorithms and insights
Data Storage
Secure, scalable cloud storage
Key Data Processing Features
Real-Time Processing
Data is processed in real-time with latency under 50ms at the edge and under 500ms end-to-end.
Offline Capabilities
Edge devices can operate independently during connectivity issues, with automatic synchronization when connection is restored.
End-to-End Security
All data is encrypted in transit and at rest using TLS 1.3 and AES-256 encryption standards.
Platform Data Throughput
Technical Specifications
Detailed specifications of our Industrial IoT platform components.
Hardware Specifications
AIO IHM
Display
10" capacitive multi-touch
Processor
Quad-core ARM Cortex-A72
Memory
4GB DDR4 RAM
Storage
32GB eMMC + microSD
Connectivity
Wi-Fi, Ethernet, RS-485, CAN
Protection
IP65 rated enclosure
AIO PLC
Processor
Dual-core ARM Cortex-M7
Memory
2GB DDR3 RAM
Storage
16GB eMMC
I/O
16 DI, 16 DO, 8 AI, 4 AO
Connectivity
Ethernet, Wi-Fi, RS-485, RS-232
Mounting
DIN rail or panel mount
WC100 Wireless Sensors
Battery Life
5+ years (typical usage)
Range
Up to 100m indoor, 500m outdoor
Sensors
Temperature, Vibration, Humidity
Wireless
Mesh network, 2.4GHz
Protection
IP67 rated enclosure
Dimensions
40mm x 60mm x 20mm
Software & Cloud Specifications
Edge Software
Operating System
Linux-based real-time OS
Runtime
Docker containerized applications
Protocols
Modbus, OPC-UA, MQTT, HTTP
Local Storage
Up to 30 days of data buffering
Security
Secure boot, encrypted storage
Updates
OTA updates with rollback
Cloud Platform
Hosting
AWS, Azure, or on-premises
Scalability
Up to 100,000 devices per tenant
Data Retention
Configurable (1 month to 10 years)
API
RESTful API, GraphQL
Analytics
Real-time and batch processing
ML Models
Anomaly detection, predictive maintenance
Security & Compliance
Encryption
TLS 1.3, AES-256
Authentication
OAuth 2.0, SAML, MFA
Access Control
Role-based with fine-grained permissions
Audit
Comprehensive audit logging
Certifications
ISO 27001, SOC 2, IEC 62443
Compliance
GDPR, CCPA ready
Integration Capabilities
Our platform seamlessly integrates with your existing systems and third-party services.
Industrial Protocols
Connect to virtually any industrial equipment with our comprehensive protocol support.
API & Development
Integrate with our platform using modern API standards and developer tools.
Third-Party Services
Connect with popular enterprise systems and cloud services.
Ready to Modernize Your Factory?
Start your journey to Industry 4.0 with Digital Sense Technologies. Connect your first two devices at no cost.
